A63726-04 RF Stack

PIPER PART NUMBER 63726-04 IS REPLACED BY FAA NEW PMA PART NUMBER A63726-04

FITS PIPER MODELS:

PA-28-140 S/N 28-20002 thru 28-7125471,

PA-28-150 S/N 28-1 thru 28-1760,

PA-28-160 S/N 28-1 thru 28-1760,

PA-28-180 S/N 28-671 thru 28-1760

This Right Front Exhaust Stack is manufactured in a state of the art facility and welded by a world class team, using aerospace grade 321 stainless steel, which provides reliable service and resist corrosion in high temperature exhaust system conditions.

AIRCRAFT MAKE / MODEL: PIPER

PARTS CATEGORY: RIGHT FRONT EXHAUST STACK

MATERIALS: 321 STAINLESS STEEL

PART CONDITION: AWI FAA APPROVED NEW PMA

AWI new, overhauled and repaired parts meet the FAA airworthiness requirements.

AIRWORTHINESS DIRECTIVE (AD) AD 70-16-05 50 HOUR OR 100 HOUR INSPECTION ON MUFFLER PART NUMBER 63627-00 OR 63688-00.

AD DOES NOT APPLICABLE WHEN MUFFLER PART NUMBER 99482-00 OR 99482-02 IS INSTALLED

RIGHT FRONT & LEFT FRONT EXHAUST STACKS SERIAL NUMBER 28-715472 AND UP RISER LEGS ARE 2" LONGER

PA 28-140 MUFFLER (0-320) PART NUMBER 99482-00 IS 1" SHORTER THAN PA 28-180 MUFFLER (0-360) PART NUMBER 99482-02
